PHASE CUT DIMMABLE DRIVER
Features: 1. Dimming With Any Phase Cut Home Automation
as well as Dimmer (Regulator)
2. Smooth linear Dimming & Flicker free
3. Dimming upto 1%
4. Compatible with both leading & trailing edge Phase Cut Home Automation
Product Details:
Phase-cut dimmable LED drivers provide a convenient and effective way to control the brightness of LED lights in various applications, allowing users to adjust the lighting levels to their desired ambiance or task requirements.
Phase-cut dimming is a common method used for dimming LED lights in residential and commercial applications. It involves reducing the input voltage to the LED driver by chopping off a portion of the AC waveform. This chopping is achieved using a TRIAC (Triode for Alternating Current) device in the dimmer switch. By adjusting the conduction angle of the TRIAC, the dimmer can control the average power supplied to the LED driver, thus dimming the LED lights.
Model No: JUNCTDN-6-18W
O/P Wattage Range : 4W to 15W
| Length | 75mm |
| Breadth | 34mm |
| Height | 18mm |
| Connector | No |
| Prewired | Yes |
| Weight | 42 grm |
| Values | Parameters |
|---|---|
| Input Voltage | 220V-240Vac |
| Input Wattage | 6W-18W |
| Output Wattage | 4W-15W |
| Frequency | 50-60Hz |
| Power Factor (full load) | >0.9 |
| THD (full load) | <10% |
| Efficiency (full load) | >80% |
| Inrush Current | <6A |
| O/P Current Type | Constant Current |
| O/P Current Tolerance | 3% |
| Galvanic Isolation | SELV |
| Dimming method | Phasecut |
| Leading Edge | Yes |
| Trailing Edge | Yes |
| Dimming Range | 1-100% |
| Surge Protection | 6KV |
| Over Voltage Protection | Yes |
| Over Current Protection | Yes |
| Short Circuit Protection | Yes |
| Class | || |
| Suitable for Emergency Lighting | No |
| Isolated | Yes |
| Ambient Temperature | 50°C |
| Case Temperature | 70°C |
| Enclosure Material | Plastic |
| Enclosure Color | White |
